Technical features

• Amplifier (program power): 2500 W (LF) – Class D Bi-amplified
• Input Sensitivity: 2 dBu – 1 V
• Input Impedance: 20 kΩ
• Mains: Universal switch mode Power Supply 85-265 V / 45-65 Hz – Overvoltage protection > 250 V
• Average current draw: 3.5 A (Heavy duty musical program)
• SPL (1m) 133 dB continuous, 136 dB peak
• Built-in DSP: 48 bit
• AD/DA converters: 24 bit – 96 kHz
• Presets: LPF80 / LPF80+3 / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF110 / LPF110+3 / LPF120 / LPF120+3 / CARDIOID + 23 configurable user memories
• Frequency response (-10 dB): 28 Hz – 120 Hz
• LF: 21” Neodymium woofer (5.3” voice coil)
• Directivity (HxV): Omnidirectional
• Dimensions (HxWxD): 668 x 749 x 900 mm
• Weight: 75.8 Kg

Physical features

• Multilayer Baltic birch plywood
• Front steel grille with grey micro-foam cloth
• High resistant bi-component black Polyurea® coating
